1/8" - 3/2 WAY SOLENOID VALVE - AIGNEP

The AIGNEP Model 01VS43NC02 solenoid valve is an electro-pneumatic pilot-operated valve from the 01V Series, designed for efficient fluid control in industrial applications.

This is a 3/2-way (3-way, 2-position) monostable valve with a Normally Closed (NC) function. Its reset or return is electro-pneumatic or solenoid with spring return. The threaded connection is 1/8".

The valve uses a coil with a voltage of 24V DC and a minimum power of 2W - 3VA. Its body is made of anodized and varnished aluminum (for sizes from 1/8" to 1/2"), with a chemically nickel-plated aluminum slide and NBR seals. It can operate in an ambient temperature range of -10°C to +60°C.

This solenoid valve is ATEX certified (Ex II 2G/D T6) for use in potentially explosive areas, complies with RoHS and PED directives, and references REACH standards.

Components that make it up:
