1/8" SOLENOID VALVE - 3/2 WAY (WITHOUT COIL) - AIGNEP

The AIGNEP 01VS43NC02 solenoid valve is an electro-pneumatic pilot valve, belonging to the robust 01V Series, ideal for fluid control in industrial environments.

This is a 3/2-way (3-way, 2-position) monostable valve with a Normally Closed (NC) function. Reactivation is achieved via electro-pneumatic or spring return. The threaded connection is 1/8".

The valve body is made of anodized and varnished aluminum, while the spool is made of chemically nickel-plated aluminum and the seals are made of NBR. It can operate with a working pressure (monostable) of 2 to 10 bar and in an ambient temperature range of -10 °C to +60 °C.

Regarding its regulatory compliance, the valve has ATEX certification (Ex II 2G/D T6) for explosive atmospheres, and complies with RoHS, PED and REACH reference standards.
