SIEMENS NH FUSE WITH CENTERED BLADES - 3NA3032

This is a Siemens NH fuse with centered blades, belonging to the 3NA3 series, NH0 size, and gG type. It is designed for selective line protection and system protection in construction companies and industrial sectors.

Rated voltage: 500V AC.

Rated current: 125A.

High breaking capacity: Yes.

Dimensions: It has a total length of 126 mm, with a body length of 67 mm and a width of 30 mm.

Blade orientation: Centered.

This product complies with rigorous standards and certifications, such as IEC 60269-1, IEC 60269-2, EN 60269-1, DIN VDE 0636, and CSA 22.2.
